उत्पत्ति के प्लेस:
चीन
ब्रांड नाम:
Cartesysj
प्रमाणन:
CE
मॉडल संख्या:
CTDCG-3-4WD
वीडियो
वीडियो
वीडियो
वीडियो
Product description:
Technical parameters:
| Model | CTDCG-3-4WD | CTDCG-10 | CTDCG-13 |
|
Maximum axle-load (kg) |
3000 | 10000 | 13000 |
|
Maximum absorption power (kw) |
160 | 250 | 300 |
|
Maximum braking torque (Nm) |
1600 | 2500 | 3000 |
|
Maximum testing speed (km/h) |
130 | 130 | 130 |
|
Drum diameter x length (mm) |
∮216×1000 | ∮318×1000 | ∮373×1000 |
|
center distance (mm) |
480 | 495 | 600 |
|
Inside the drum width/width (mm) |
700/2700 | 700/2700 | 700/2700 |
|
Working voltage (current) |
96V ×35A | 96V ×35A | 96V ×35A |
|
The power supply |
220V ±10% 50HZ | 220V ±10% 50HZ | 220V ±10% 50HZ |
